Diamond-coated wire cutter also known as diamond wire saw is a specific cutting method that utilizes frictional force of wire operating at a high speed to grind through the material. Diamond is the material used for cutting since it has the highest hardness on earth and can cut through almost any material. Diamond wire saws are used in a diverse range of industry projects. The cutting equipment design consists of diamond and synthetic rubber rings that are joined together.
The main function of the diamond saw is to slice through brittle and hard materials. The cutting method usually involves placing the wire saw on material supposed to be cut and then the saw is run at high speed to cut and shape the material. Diamond wire saw is also used for mining stones and quarrying, and the quarry can reach a depth of 10 to 20 meters. Once the wire saw is in operation, it produces a lot of heat since it generates friction to accomplish the cutting effect. That is why the diamond wire saw cannot be operated for a long duration nonstop, since the excessive heat dissipation can wear down the components.
So, to maximize the service life it is advisable to turn it off periodically to allow it to cool down. The cooling method most frequently used in the industry is water circulation cooling. Other cooling methods use oils or cutting fluids for cooling the diamond wire equipment. The oil or cutting fluids also lubricate the machine so that it retains its cutting efficiency.
Diamond-coated wire cutter is a tool that is used quarrying granite, and it is widely preferred as a cutting method in the mining sector because:
Diamond wire saw can be used in any type of mining project. It definitely has the edge over blast mining that can only be use in just granite mines that have a high quartz content and a lack of fissures.
The diamond wire saw is able to penetrate to a greater depth and reach up to 20 meters. But the blast mining method has a penetration of only up to 10 meters. Moreover, the cutting speed of the diamond wire cutter is higher than blast mining by double or triple the rate.
Diamond wire saw can cut in every direction: vertical, horizontal, and even bevel cutting. Blast-type cutting cannot match the flexibility of a diamond saw, as it only cuts in the vertical direction.
The surface of the diamond wire saw is flat and so it does not cause any fracturing of material that is being cut. The sawing gap of the wire saw is also quite narrow at only 11 mm, and this narrow gap means a more precise cutting operation with minimal material wastage. This is not the case with the blast cutting method, where the sawing gap is large, about 100mm-300mm, and this huge gap greatly reduces cutting accuracy and causes material wastage.
During the cutting operation using a diamond saw, the cutting is silent and produces no noise pollution. The cutting operation also produces no dust and debris that may affect the nearby population. Moreover, diamond wire saw mining and cutting operations are largely automated and do not require much hands-on worker involvement, which translates to better safety and lower accidental risk.
This is a common problem that is encountered when the parameters are not set correctly by the operator. So, having knowledge about how to operate the cutting technology is vital in this cutting method. Another reason for this problem is that the wire saw quality is substandard. The rubber or plastic that bonds the diamond bead is rendered weak if the saw quality is poor.
A range of conditions can give rise to bead flaking. One of them is incorrect sintering parameters. Another cause is a wrong or faulty cold pressing process. Neglect in cleaning of the beaded steel body also results in bead flaking.
This problem is related to the manufacturing quality of the saw rather than an operational or maintenance fault. In some cases, the wire saw is made from a diamond that is too hard and highly dense. Although hardness is preferred a too hard diamond does not chip easily and so the cutting tip lacks the sharp edge that a softer diamond would have easily produced.
This is also a manufacturing fault and results when the beads are loosely bonded. A range of issues give rise to weak bonding, such as a bad selection of steel wire, improper cleaning, and a faulty injection molding process during diamond-coated wire cutter manufacture.
Before beginning the cutting operation, make sure that the direction of the wire saw is not facing opposite to the direction of rotation of the cutting. Make sure that the cutting direction is aligned with the arrow of each card.
Steep cutting angles can damage the wire so avoid slicing at a sharp angle.
Utilize a guide wheel as it enhances cutting efficiency and also increases cutting speed. To keep the usage life maximum, timely replacement of the rubber ring in the guide wheel is vital.
Wire saw cutting heats up the tool due to friction, so cooling with water is crucial. However, balance in cooling should be maintained as too much cooling affects the wire and causes slippage, which brings down the cutting accuracy. Too little water usage is also not good, as it will cause the string beads to erode faster. The amount of water cooling needed is closely tied to the cutting situation.
Diamond-coated wire cutter provides an innovative solution to the best service provider grouping for industries that require precision, waste control, and even challenging cutting materials. By using a loop of wire with industrial diamonds as the cutting medium, diamond-coated wire cutter
provides clean, precise cuts through hard materials including stone, concrete, glass, and some metal alloys at remarkable speed.
As the pace of development is driven by innovation that supports speed, automation, and environmental commercial responsibility, the tools on offer in diamond-coated wire cutter will be fundamental in offering shape to everything from skyscrapers and bridges to precision electronic components that are also made from materials that evolved from diamond wire. Knowing how diamond-coated wire cutter works and what it works best on means a business is more informed to make better progressive decisions, informed, sustainable decisions in both their cutting and fabrication.
1. What materials diamond-coated wire cutter cut?
It can cross-cut a wide variety of rough materials, as well as brittle or delicate, such as granite, marble, concrete, glass, ceramics, and alloys. Its diamond abrasives (of industrial grades) make it suitable to use on natural materials as well as engineered work.
2. How does diamond wire cutting differ from traditional cutting methods?
Diamond wire cutting does not require the use of saw blades or any thermal method of cutting . It generates less heat, reduced loss of material and it is possible to make smoother and cleaner cuts at the same time causing less structural stress.
3. Where is diamond wire cutting commonly used?
The following are some of the sectors in industry that widely use this technology; construction, mining, quarrying, semiconductor manufacturing and construction destruction. It is particularly useful when high accuracy demands and small vibrations are needed, and large or complicated structures have to be cut.
